2023 FORD EcoSport Instrument Cluster
Welcome to the in-depth manual that reveals the instrument cluster for the 2023 Ford EcoSport, a technical marvel. We set out on an exploration of the sophisticated display in this introduction to raise the bar for your driving experience by putting critical data and connectivity at your fingertips. The 2023 Ford EcoSport’s instrument cluster acts as a dynamic and interactive window into the status and functionality of your car. It is a digital command centre that offers in-line controls, intuitive insights, and real-time data. The instrument cluster improves safety in addition to offering information. Critical alerts and cautions are quickly displayed to keep you informed of potential threats and vehicle issues, further enhancing your sense of security and confidence while driving This manual will be your dependable travel companion as you explore the digital world of the Instrument Cluster in the 2023 FORD EcoSport, whether you’re a tech-savvy driver looking to master the art of digital instrumentation or simply seeking to maximize the technology in your vehicle.
Instrument Cluster
Vehicle Settings and Personalization
See General Information.
Engine Coolant Temperature Gauge
WARNING: Do not remove the coolant reservoir cap when the engine is on or the cooling system is hot. Wait 10 minutes for the cooling system to cool down. Cover the coolant reservoir cap with a thick cloth to prevent the possibility of scalding and slowly remove the cap. Failure to follow this instruction could result in personal injury.
At normal operating temperature the indicator will remain in the center section.
If the needle enters the red section, the engine is overheating. Stop the engine, switch the ignition off and determine the cause once the engine has cooled down. See Engine Coolant Check .
Note: Do not restart the engine until the cause of overheating has been determined and resolved.
Fuel Gauge
Switch the ignition on. The fuel gauge will indicate approximately how much fuel is left in the fuel tank. The fuel gauge may vary slightly when your vehicle is moving or on a gradient.
The arrow adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel filler door is located.
The fuel filler door is on the left-hand side of your vehicle.
The fuel filler door is on the right-hand side of your vehicle.
WARNING LAMPS AND INDICATORS
The following warning lamps and indicators alert you to a vehicle condition that may become serious. Some lamps illuminate when you start your vehicle to make sure they work. If any lamps remain on after starting your vehicle, refer to the respective system warning lamp for further information.
Note: Some warning indicators appear in the information display and operate the same as a warning lamp but do not illuminate when you start your vehicle.
Airbag Warning Lamp
If it does not illuminate when you switch the ignition on, continues to flash or remains on when the engine is running, this indicates a malfunction. Have your vehicle checked as soon as possible.
Anti-Lock Brake System Warning Lamp
If it illuminates when you are driving, this indicates a malfunction. Your vehicle
continues to have normal braking without the anti-lock brake system function. It also illuminates momentarily when you switch the ignition on to confirm the lamp is functional. If it does not illuminate when you switch the ignition on, or begins to flash at any time, have the system checked by an authorized dealer. Have your vehicle checked as soon as possible.
Brake System Warning Lamp
WARNING: Driving your vehicle with the warning lamp on is dangerous. A significant decrease in braking performance may occur. It may take you longer to stop your vehicle. Have your vehicle checked as soon as possible. Driving extended distances with the parking brake engaged can cause brake failure and the risk of personal injury.
It illuminates when you engage the parking brake and the ignition is on.
If it illuminates when your vehicle is moving, make sure the parking brake is disengaged. If the parking brake is disengaged, this indicates low brake fluid level or a brake system fault. It also illuminates momentarily when you switch the ignition on to confirm the lamp is functional. If it does not illuminate when you switch the ignition on, or begins to flash at any time, have the system checked by an authorized dealer. Have your vehicle checked immediately.
Direction Indicator
Flashes during operation. An increase in the rate of flashing warns of a failed indicator bulb.
Fasten Seatbelt Warning Lamp
It illuminates and a chime sounds until you fasten the seatbelts.
Front Fog Lamp Indicator (If Equipped)
It illuminates when you switch the front fog lamps on.
Headlamp High Beam Indicator
It illuminates when you switch the headlamp high beam on.
Battery
It illuminates when you switch the ignition on.
If it illuminates when the engine
is running this indicates a malfunction.
Switch off all unnecessary electrical equipment. Have your vehicle checked as soon as possible.
Parking Lamps
It will illuminate when you switch the parking lamps on.
Low Fuel Level Warning Lamp
If it illuminates when you are driving, refuel as soon as possible.
It illuminates if the tire pressure in one or more tires is below the correct tire pressure.
Auto Start-Stop (If Equipped)
It illuminates to inform you when the engine shuts down or in conjunction with a message.
Service Engine Soon
If it illuminates when the engine is running this indicates a malfunction. The On Board Diagnostics system has detected a malfunction of the vehicle emission control system.
If it flashes, engine misfire may be occurring. Increased exhaust gas temperatures could damage the catalytic converter or other vehicle components. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle immediately serviced.
It illuminates when you switch the ignition on prior to engine start to check the bulb and to indicate whether your vehicle is ready for Inspection and
Maintenance
(I/M) testing.
Normally, it illuminates until the engine is cranked and automatically turns off if no malfunctions are present. However, if after 15 seconds it flashes eight times, this indicates that your vehicle is not ready for Inspection and Maintenance (I/M) testing.
See Catalytic Converter .
Powertrain Malfunction
If it illuminates when driving, a powertrain fault has been detected. Contact your authorized dealer as soon possible.
Oil Pressure Warning Lamp
It illuminates when you switch the ignition on.
If it illuminates when the engine is running this indicates a malfunction. Stop your vehicle as soon as it is safe to do so and switch the engine off. Check the engine oil level. If the oil level is sufficient, this indicates a system malfunction. Have your vehicle checked immediately. See Engine Oil Check (page 215).
Engine Coolant Temperature Warning Lamp
WARNING: Do not remove the coolant reservoir cap when the engine is on or the cooling system is hot. Wait 10 minutes for the cooling system to cool down. Cover the coolant reservoir cap with a thick cloth to prevent the possibility of scalding and slowly remove the cap. Failure to follow this instruction could result in personal injury.
Note: Do not restart the engine until the cause of overheating has been determined and resolved.
Note: Do not resume your journey if it illuminates despite the level being correct. Have the system checked by your authorized dealer immediately.
Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Check the coolant level. See Engine Coolant Check .
If it stays on after starting or illuminates when driving, this indicates a malfunction.
Blind Spot (If Equipped)
It will illuminate when you switch this feature off or a fault has been detected. Contact your authorized dealer as soon possible.
Door Ajar Warning Lamp
Illuminates when you switch the ignition on and remains on if any door, the hood or the liftgate is not closed properly.
Stability Control and Traction Control Off Warning Lamp
It illuminates when you switch the system off.
See Stability Control x
Stability Control and Traction Control Indicator Flashes during operation.
If it does not illuminate when you switch the ignition on, or remains on when the engine is running, this indicates a malfunction. Have your vehicle checked as soon as possible.
Note: The system automatically turns off if there is a malfunction.
See Using Traction Control See Using Stability Control .
FAQ
The instrument cluster is a dashboard-mounted digital display panel that shows vital vehicle data like speed, fuel level, temperature, and more.
Yes, a lot of contemporary instrument clusters support customisation. The information that is displayed and the way it is presented are frequently your choices.
Depending on the model, you can frequently switch between screens by pressing buttons on the steering wheel or utilizing the touchscreen.
Some models may allow you to do so, enabling you to access some apps and receive notifications on the instrument cluster.
Yes, modern instrument clusters typically contain brightness settings that may be changed to ensure clear visibility throughout both day and night.
Turn-by-turn navigation directions can be shown on some models’ instrument clusters, which can assist you in maintaining your attention on the road.
The Instrument Cluster frequently shows warning symbols and messages to notify you of problems like low oil pressure, the check engine light, or low tire pressure.
Yes, a lot of instrument clusters offer real-time fuel efficiency data to encourage you to drive more sustainably.
Yes, you may frequently reset maintenance alerts, including indications of an upcoming oil change, using the buttons on the instrument cluster.
The Instrument Cluster may have numerous language options, depending on the model and area.
It’s possible to update the software on the Instrument Cluster. Information about software upgrades can be found by contacting your dealer or the manufacturer.
Consult your owner’s manual for troubleshooting instructions if you’re having problems with the instrument cluster, or get professional help.
Depending on the model, voice commands may let you engage with specific elements of the Instrument Cluster
In some vehicles, you can choose between driving modes using buttons on the steering wheel or the touchscreen interface on the instrument cluster.
Remember that depending on the model and trim level of your 2023 FORD EcoSport, the particular features and functionality of the Instrument Cluster may change. For complete details and directions, always refer to your owner’s handbook.
