2024 Indian Motorcycle Springfield Fuses and Fuse Box | How to fix a Blown Fuse
An extensive electricity system is built into the 2024 Indian Motorcycle Springfield to make sure that all of its parts work smoothly. The fuse box is an important part of this system because it protects the electrical circuits on the motorbike. There are several fuses in the fuse box. Each one is put in a specific way to protect different parts from electrical overloads or faults. If there is a problem or too much power, a fuse may blow, cutting off the circuit and stopping any damage that might happen. To fix a blown fuse, riders need to find the fuse box, which is usually placed somewhere easy to get to. Once the blown fuse is found, it is very important to identify it using a multimeter or a visual check. Changing the blown fuse with a spare that fits makes sure that the electrical system works again, so riders can quickly fix electrical problems and get back on the road. Everyone who rides a motorbike needs to know how the fuse system works. This makes riding safer and more reliable.
FUSE REPLACEMENT
NOTICE
Use fuses with the recommended amperage to avoid damage to the electrical system.
STANDARD FUSES
The standard fuse box is located under the left side cover. This fuse box houses all standard service fuses and the automatic circuit breakers. Fuse application and size are provided on a label on the fuse box cover.
TIP
Use the fuse puller provided in the tool kit to remove a fuse.
| MAt.l ENGH: RELAY |
START RELAY |
AUX SW POWER RELAY | FUEL
PUMP RELAY |
SEC
ENGi£ RELAY |
SWITCl-£0 PWR RLY |
| 20A
MAIN ENG |
20A
AUX SWITCtED |
10A
SEC- |
10A
SW PWft |
||
| 7.5A
IONIT10N COL |
10A
VCM CONTAOI. |
15A
AUX CONST |
5A
OAUOI! |
25A
FIIONT NIIP |
25A |
- Remove the left side cover. See page 141.
- To release the locking tabs, squeeze the upper and lower cover clips and remove the fuse box cover.
- After replacing a fuse, reinstall the fuse box cover and side cover.
HIGH-CURRENT FUSES
The JCASE® fuse box q contains the high-current fuses for the chassis, vehicle control module, and anti-lock brake system. This fuse box is located next to the battery box.
Fuse application and size are provided on a label on the fuse box cover.
ELECTRICAL PRECAUTIONS
Be aware of the following precautions regarding the electrical system to avoid disruption of electrical signals and possible system malfunction.
- DO use ONLY genuine INDIAN MOTORCYCLE parts and accessories designed for your model, and follow the instructions provided.
- DO use the accessory power jack provided (if equipped).
- If it is necessary to provide power to an item that does not use one of the previously mentioned power jacks, connect to the load side of the main circuit breaker and connect the ground wire to the engine ground at the front left side of the crankcase (near the circuit breaker). On DARK HORSE models the circuit breaker is located under the cover next to the oil filter adapter. On all other models, it’s located under the cover behind the oil cooler.
- DO NOT splice or cut any wires.
- DO NOT tap into any power or ground on the motorcycle unless specifically directed to do so by the INDIAN MOTORCYCLE instructions that come with the kit.
- DO NOT back-probe electrical connectors on the vehicle unless directed to do so by the INDIAN MOTORCYCLE Service Manual.
- DO NOT power any accessories from the diagnostic connector (under the left side cover).
UNLOCKING THE SECURITY SYSTEM
Your dealer will provide the master personal identification number (PIN) for the security system. Your dealer may also change the master PIN to a new rider PIN on your behalf.
Record both PINs on page 7.
Change the dealer-provided PIN to a PIN of your choosing as soon as possible after receiving delivery of your new motorcycle. See page 154.
If a key fob is not available, your rider PIN can be entered using the turn signal switches to unlock the security system. Use the following guide to enter your valid rider PIN.
| DIGIT TO ENTER | TURN SIGNAL FEATURE USED | PROCEDURE |
| The number “0” | CANCEL switch | Press and release |
| First digit (1-9) | LEFT turn switch |
Move and release once per digit value. See the example below. |
| Second digit (1-9) | RIGHT turn switch | |
| Third digit (1-9) | LEFT turn switch | |
| Fourth digit (1-9) | RIGHT turn switch | |
| Example for entering the number 1024:
LEFT – CANCEL – LEFT – LEFT – RIGHT- RIGHT- RIGHT- RIGHT |
||
CHANGING YOUR SECURITY SYSTEM PIN
To change your PIN, you must have either the key fob or your existing valid PIN available to gain access to the security system. If the key fob is not detected or is not available and you cannot remember your PIN, please see your INDIAN MOTORCYCLE dealer.
Please read the entire procedure before beginning.
- Turn the power switch on. Do NOT start the engine. The security light and/or power switch will turn on briefly until the key fob is detected or until the valid, current PIN is entered.
- Push or hold the turn signal CANCEL switch for 10 seconds until the security light and/or power switch turn on.
NOTICE
On models with Infotainment Display, a pop-up window will appear during this procedure stating that the key fob is out of range. - Enter either the master PIN (see page 7) or your current 4-digit rider PIN within 20 seconds. If the PIN is successfully entered, the security light and/or power switch will remain on and the horn will sound briefly.
NOTICE
If the valid PIN is not entered within 20 seconds, the security light and/or power switch will flash for 10 seconds, then the system will shut down. Return to step 1 to try again. - Enter a new 4-digit security PIN of your choosing. If the PIN is successfully entered, the security light will remain on and the horn will sound briefly. Proceed to step 5.
NOTICE
If the 4-digit PIN is NOT successfully entered within 20 seconds, the security light will flash for 10 seconds, then the system exits the procedure. Return to step 1 to try again. - Re-enter the new 4-digit PIN. If this entry matches the first entry, the security light will turn off and the horn will sound briefly. The new rider PIN has been saved. Record your new rider PIN on page 7.
NOTICE
If the second entry is not entered within 20 seconds or does not match the first entry, the security light will flash for 10 seconds, then the system exits the procedure. The new PIN was NOT saved. Continue to use your former valid PIN. Return to step 1 to try again.
ENGINE COMPRESSION TEST
An engine compression test can be performed to monitor general engine conditions. See the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN MOTORCYCLE dealer can assist.
EXHAUST SYSTEM INSPECTION
Check the exhaust system for stains from leaking exhaust gasses. Replace damaged or leaking exhaust gaskets. Check all exhaust system fasteners. Tighten loose clamps and fasteners. Do not over-tighten. See the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN MOTORCYCLE dealer can assist.
ELEVATING THE MOTORCYCLE
WARNING
Serious injury or death can occur if the motorcycle tips or falls. Make sure the motorcycle will not tip or fall while elevated or while on the side stand.
Some procedures require raising the motorcycle to remove weight from the component being inspected. Elevate the motorcycle by placing a stable, flat platform jack or lift mechanism on a firm, flat surface and lifting under the engine crankcase. The platform should be a minimum of 12 in (30 cm) square. DO NOT attempt to lift the motorcycle without proper equipment. Always secure the motorcycle properly before lifting it so it cannot tip or fall when elevated.
ROAD TEST
Before returning the motorcycle to regular use, perform a road test in a safe area. Pay special attention to the proper fit and operation of all serviced components.
Make any corrections or additional adjustments promptly to ensure safe, reliable, and enjoyable vehicle performance.
FASTENER INSPECTION
- Inspect the entire motorcycle chassis and engine for loose, damaged, or missing fasteners. Tighten loose fasteners to the proper torque. See the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN MOTORCYCLE dealer can assist.
- Always replace stripped, damaged, or broken fasteners before riding. Use genuine INDIAN MOTORCYCLE fasteners of equal size and strength.
FASTENER TORQUES
Some procedures and fastener torques are not listed in this manual. See the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN MOTORCYCLE dealer can assist.
TROUBLESHOOTING
For your safety, do not attempt inspection or repairs not fully described in this rider’s manual. Contact an authorized dealer for service if you cannot determine the cause of a problem or if the inspection/repair exceeds your mechanical ability or tool resources. Do not perform any inspection or repair with the engine running.
ENGINE CRANKS BUT WILL NOT START
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Low Fuel | Verify fuel level. |
| Fuel Pump Inoperative | Turn the engine STOP switch to RUN. Turn the power switch on. The fuel pump should run momentarily and then stop. Check the fuel pump/ignition circuit breaker. |
| Battery Voltage Too Low | Fully charge the battery. |
| Spark Plug(s) Fouled | Inspect spark plugs. |
| Spark Plug Wire(s) Disconnected or Loose | Be sure spark plug wires are securely fastened. |
| Low Compression | Please see your dealer for an engine compression test. |
THE STARTER MOTOR CLICKS, DOES NOT TURN OR TURNS SLOWLY
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Engine Stop/Run Switch in Stop Position | Place the switch in the RUN position. |
| Battery Discharged | Fully charge the battery. |
| Battery Cables Lose or Corroded | Inspect battery cables. |
| Transmission In Gear | Shift the transmission into neutral or pull the clutch lever in to disengage the clutch. |
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Key Fob Not Authenticated | Make sure the key fob is within range and that the key fob battery voltage is not low. |
| Sidestand is Down With Transmission in Gear | Shift to neutral or retract the side stand fully. |
ENGINE STARTS BUT MISSES OR RUNS POORLY
NOTICE
Turn the engine OFF before inspecting any of these items.
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Battery Discharged | Fully charge the battery. |
| Battery Cables Lose or Corroded | Inspect battery cables and connections. |
| Spark Plug(s) Fouled | Inspect spark plugs. |
| Spark Plug Wire(s) Loose or Wet | Inspect spark plug wires, and ensure they dry/secure. |
| Contaminated Fuel | Inspect fuel for water/contamination. Please see your dealer. |
| Engine Oil Level Incorrect Or Wrong Type | Inspect the level and quality of the oil. |
| Loose, Broken, Shorted Ignition Coil Wires | Inspect coil primary wires. Please see your dealer. |
| Air Intake Restricted | Inspect the air filter. |
| Intake Leaks | Inspect the air box, throttle body, and intake boot joints. |
SHIFTING DIFFICULTIES OR HARD-TO-FIND NEUTRAL
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Shift Linkage Bushings Dry Or Worn | Lubricate shift linkage. |
| Clutch Damage | Replace clutch. |
| Clutch Cable Not Adjusted Properly | Please see your dealer for inspection and adjustment. |
| Shift Linkage Not Adjusted Properly | Please see your dealer for inspection and adjustment. |
BATTERY CHARGING RATE LOW OR BATTERY DISCHARGES
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Loose/Corroded Charging Circuit Connection | Check/clean battery cable connections. Check/clean charging circuit connections. Please see your dealer. |
| Accessory Load Exceeds Charge Rate | Limit accessory operation when the engine is off. |
| Improperly Wired Accessory (Current Draw) | Please see your dealer to check the charging system output and current draw. |
BRAKE NOISE/POOR BRAKE PERFORMANCE
NOTICE
See your dealer if brake performance does not return after these inspections.
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Dust/Dirt On Brake Disc(s) | Clean disc. |
| Worn Pads Or Disc/Brake Disc Damage | Inspect pads. |
| Brake Fluid Level Low Or Fluid Contaminated | Inspect fluid level/fluid condition. |
ANTI-LOCK BRAKE LIGHT REMAINS ILLUMINATED OR ILLUMINATES INTERMITTENTLY
| POSSIBLE CAUSE | POSSIBLE REMEDY/ACTION |
| Blown fuse | Check the fuses. See page 151. |
| Loose or damaged pulse ring | Inspect the pulse ring for looseness or chipped teeth. |
| Debris lodged in components | Inspect the wheel speed sensor and pulse ring for debris. |
| Damage caused by debris | Inspect wheel speed sensor for cracked housing. |
| Damaged components | See the service manual or authorized dealer. |
FAQs
Fuses in the 2024 Indian Motorcycle Springfield serve to protect the electrical system by interrupting the circuit when there is an excessive current flow, preventing damage to components.
The number of fuses may vary, but there are typically multiple fuses in the fuse box of the 2024 Indian Motorcycle Springfield.
Fuses protect various electrical components, including lights, ignition systems, audio systems, and other electronic devices in the motorcycle.
Look for a broken wire inside the fuse or a visibly melted or discolored appearance. Also, the metal strip inside a transparent fuse may be broken if it’s blown.
The fuse box is usually located in a readily accessible area, often under the seat or near the battery compartment.
You typically only need a set of pliers or a fuse puller, which is often included in the motorcycle’s toolkit.
No, it’s essential to replace the blown fuse with the same amp rating to maintain proper protection for the electrical system.
It’s common for manufacturers to include spare fuses in the motorcycle’s toolkit.
Blown fuses can result from short circuits, overloads, or faults in the electrical system.
See the motorcycle’s manual for the correct procedure, but generally, it involves identifying the blown fuse, pulling it out using a fuse puller or pliers, and inserting a new fuse.
Yes, depending on which circuit the blown fuse protects, it can impact various aspects of the motorcycle’s performance.
While it’s advisable to use the manufacturer-recommended fuses, compatible aftermarket options may be available.
Regularly inspect the fuses during routine maintenance or if you experience electrical issues to catch and replace any blown fuses promptly.
Yes, extreme temperatures or moisture can potentially impact the electrical system and contribute to blown fuses.
If replacing the fuse doesn’t fix the problem, consult the motorcycle’s manual for troubleshooting tips or seek professional assistance from a certified technician.
