2022 Mitsubishi Outlander Fuses and Fuse Box | How to fix a blown fuse
The fuses and fuse box of the 2022 Mitsubishi Outlander are essential for protecting the electrical systems of the car. There are normally two main fuse boxes, one in the engine compartment and the other in the interior cabin. Both contain different types of fuses. These fuses guarantee that the car’s numerous systems run smoothly by guarding against overloads and short circuits on particular electrical circuits. A fuse that blows as a result of an electrical malfunction breaks the circuit, averting possible harm to important systems. The safe and effective operation of the Outlander’s electrical functions depends on routinely monitoring them and understanding how to repair a blown fuse.
2023 Mitsubishi Outlander Specs, Price, Features, Mileage (Brochure)
FUSES
ENGINE COMPARTMENT
WARNING
Never use a fuse of a higher or lower amperage rating than that specified on the fuse box cover. This could damage the electrical system or electronic control units or cause a fire.
If any electrical equipment does not operate, check for an open fuse.
-
Be sure the ignition switch and the head-light switch are turned off.
-
Open the engine hood.
-
Remove the fuse/fusible link box cover by using a suitable tool and pushing the tab.
-
Locate the fuse that needs to be replaced.
-
Remove the fuse using the fuse puller located in the passenger compartment fuse box.
-
If the fuse is open , replace it with a new fuse .
-
If a new fuse also opens, have the electrical system checked and repaired. It is recommended you visit an authorized Mitsubishi Motors dealer for this service.
Fusible links
If any electrical equipment does not operate and the fuses are in good condition, check the fusible links. If any of these fusible links are melted, replace only with genuine Mitsubishi Motors parts. For checking and replacing the fusible links, it is recommended you visit an authorized Mitsubishi Motors dealer.
PASSENGER COMPARTMENT
WARNING
Never use a fuse of a higher or lower amperage rating than that specified on the fuse box cover. This could damage the electrical system or electronic control units or cause a fire.
If any electrical equipment does not operate, check for an open fuse.
- Be sure the ignition switch and the headlight switch are turned off.
-
Remove the fuse box cover.
-
Remove the fuse with the fuse puller.
-
If the fuse is open, replace it with a new fuse.
-
If a new fuse also opens, have the electrical system checked and repaired. It is recommended you visit an authorized Mitsubishi Motors dealer for this service.
2023 Mitsubishi Outlander Specs, Price, Features, Mileage (Brochure)
Extended storage fuse switch
To reduce battery drain, the extended storage fuse switch comes from the factory switched off. Prior to delivery of your vehicle, the switch is pushed in (switched on) and should always remain on. If the extended storage fuse switch is not pushed in (switched on), the meter may display a warning message. If any electrical equipment does not operate, remove the extended storage fuse switch and check for an open fuse.
NOTE:
If the extended storage fuse switch malfunctions or if the fuse is open, it is not necessary to replace the switch. In this case, remove the extended storage fuse switch and replace it with a new fuse of the same rating.
How to remove the extended storage fuse switch:
- To remove the extended storage fuse switch, be sure the ignition switch is in the OFF or LOCK position.
- Be sure the headlight switch is in the OFF position.
-
Remove the fuse box cover.
-
Pinch and pull out the extended storage fuse switch.
-
Pull the extended storage fuse switch straight out from the fuse box.
FAQs
Fuses in the 2022 Mitsubishi Outlander are designed to protect the vehicle’s electrical circuits by breaking the circuit in case of overloads or faults.
The fuse box in the 2022 Mitsubishi Outlander is typically located under the dashboard on the driver’s side or in the engine compartment.
To access the interior fuse box, simply open the driver’s side door and look for a removable panel on the side of the dashboard. In the engine compartment, the fuse box is usually covered with a plastic lid that can be removed.
Yes, the Outlander may use different types of fuses, including blade-type fuses and cartridge fuses, depending on the circuit’s requirements.
Fuse colors can indicate their amperage rating. To decipher the color code used in your Outlander.
A blown fuse will have a broken filament inside. You can visually inspect the fuse or use a multimeter to test for continuity.
Fuses can blow due to electrical faults, short circuits, overloads, or faulty components within the vehicle.
Yes, replacing a blown fuse is a relatively simple DIY task. Refer to your owner’s manual for guidance on locating and replacing the specific fuse.
Yes, it’s crucial to replace a blown fuse with one of the same amperage rating to maintain the circuit’s protection.
You can purchase spare fuses at most auto parts stores or online retailers. Make sure to get the correct type and amperage rating.
Having a fuse puller or a pair of needle-nose pliers can make it easier to remove and replace fuses.
If a fuse repeatedly blows, it may indicate an underlying electrical issue. Consult your dealer or a professional mechanic for further diagnosis.
check your vehicle’s electrical system, avoid overloading circuits, and maintain your vehicle according to the manufacturer’s recommendations.
It’s generally not recommended to modify the fuse box or add circuits without proper knowledge and expertise, as it can lead to electrical issues.
It’s advisable to check with your local Mitsubishi dealer or the National Highway Traffic Safety Administration (NHTSA) for any recalls or known issues related to fuses in your specific model.
If you’ve replaced a blown fuse, but the problem persists, it’s best to consult a professional mechanic to diagnose and fix the issue.
